INA826AIDR
Part Number: INA826AIDR
Manufacturer/Brand: Texas instruments
Description: Precision instrumentation amplifier with a 200-μA supply current, 36-V supply, and 8-SOP package that provides a 100 dB gain with a 150 uV offset-max, making it perfect for amplifying low-level signals in a variety of applications
Product Category: Integrated Circuits (ICs), Amplifiers, Instrumentation Amplifiers
Package/Case: SOP-8
Stock Condition: 3,000, Can Ship in 48 Hours
Minimum: 1 Multiple: 1 Price For: Each
| Quantity | Price |
|---|---|
| 1+ | $2.89 |
| 10+ | $2.60 |
| 25+ | $2.45 |
| 100+ | $2.13 |
| 250+ | $2.02 |
| 500+ | $1.81 |
About INA826AIDR
The INA826AIDR is a highly precise and efficient instrumentation amplifier designed for a wide range of applications. With a supply current of only 200μA and a supply voltage capacity of 36V, this amplifier is capable of delivering precise results with accuracy and efficiency. This device is perfect for use in applications such as motor control, temperature measurement, and pressure sensing.
This instrumentation amplifier is equipped with an 8-SOP package and features rail-to-rail output to ensure that signals don’t clip. Moreover, it offers a high common-mode rejection ratio of 100 dB, making it ideal for use in noisy environments.
The INA826AIDR also has a low offset voltage of just 150 μV, allowing for accurate amplification of small signals. With a frequency range of 1 MHz and a temperature range of -40 to 125 degrees Celsius, this amplifier is highly versatile and can be used in a wide range of applications.
Overall, the INA826AIDR is a precise and efficient instrumentation amplifier that delivers excellent performance in a variety of applications.
Features
- Precision design with 200-μA supply current and 36-V supply voltage
- Single circuit rail-to-rail output
- 8-SOIC package with 1MHz bandwidth and 150uV max offset
- ROHS compliant and available in tape and reel packaging
- Operating temperature range of -40 to 125 degrees Celsius
Specifications
| Texas Instruments | |
| Product Category: | Instrumentation Amplifiers |
| RoHS: | Complaint |
| INA826 | |
| 1 Channel | |
| 1 MHz | |
| 1 V/us | |
| 120 dB | |
| 65 nA | |
| 150 uV | |
| 36 V | |
| 2.7 V | |
| 200 uA | |
| – 40 C | |
| + 125 C | |
| SMD/SMT | |
| SOIC-8 | |
| Reel | |
| Cut Tape | |
| MouseReel | |
| Amplifier Type: | Instrumentation Amplifier |
| Bandwidth: | 1 MHz |
| Brand: | Texas Instruments |
| Development Kit: | INA826EVM |
| Dual Supply Voltage: | 2.7 V to 36 V |
| en – Input Voltage Noise Density: | 18 nV/sqrt Hz |
| Gain Error: | 0.0005 % |
| Gain V/V: | 1 V/V to 1000 V/V |
| Ios – Input Offset Current: | 10 nA |
| Moisture Sensitive: | Yes |
| Operating Supply Voltage: | 2.7 V to 36 V |
| Output Current per Channel: | 16 mA |
| Output Type: | Rail-to-Rail |
| Product: | Instrumentation Amplifiers |
| Product Type: | Instrumentation Amplifiers |
| PSRR – Power Supply Rejection Ratio: | 100 dB |
| Shutdown: | No Shutdown |
| Subcategory: | Amplifier ICs |
| Vcm – Common Mode Voltage: | +/- 40 V |
| Unit Weight: | 0.019048 oz |
Applications
- Ideal for use in precision measurement systems and instrumentation applications
- Suitable for low-power and battery-powered systems due to its low supply current
- Can be used in medical devices for accurate diagnostic measurements
- Suitable for use in industrial automation and control systems
- Suitable for sensitive applications where high-precision signal amplification is required
