LM319MX/NOPB
Part Number: LM319MX/NOPB
Manufacturer/Brand: Texas Instruments
Description: Dual comparator IC, ±18V/36V voltage, 1uA power consumption, 8mV input offset voltage, SOIC14.
Product Category: Amplifier ICs, Analog Comparators
Package/Case: SOIC14
Stock Condition: 5,000, Can Ship in 48 Hours
Minimum: 1 Multiple: 1 Price For: Each
| Quantity | Price |
|---|---|
| 1+ | $20.67 |
| 10+ | $19.26 |
| 100+ | $16.71 |
| 500+ | $13.42 |
| 1000+ | $11.68 |
About LM319MX/NOPB
The LM319MX/NOPB is a dual comparator IC manufactured by Texas Instruments. It is designed to operate with a wide voltage range of ±18V/36V, making it suitable for various applications. The device features two comparators, allowing for the comparison of two different input signals. It has a fast response time and operates with a low power consumption of 1uA.
This IC is packaged in a small outline integrated circuit (SOIC) package with 14 pins. It is surface mount technology (SMT) compatible, which enables easy installation on circuit boards. The LM319MX/NOPB is also available in reel and tape packaging options, providing convenience for mass production.
With a typical input offset voltage of only 8mV, the LM319MX/NOPB offers high precision in comparing analog signals. It is compliant with the Restriction of Hazardous Substances Directive (RoHS), ensuring its environmental friendliness. Overall, this dual comparator IC is a reliable and versatile component for applications requiring accurate signal comparison in a compact form factor.
Features
- Wide Voltage Range: It is designed to operate with a wide voltage range of ±18V/36V, making it suitable for various applications that require high voltage levels.
- Dual Comparators: This IC features two comparators, allowing for the simultaneous comparison of two different input signals. This enables more versatile signal processing and analysis.
- Fast Response Time: It has a fast response time, ensuring quick and efficient signal comparison. This makes it suitable for applications where real-time processing is essential.
- Low Power Consumption: With a low power consumption of 1uA, the LM319MX/NOPB helps in conserving energy and prolonging battery life in portable devices or low-power applications.
- Small Outline Integrated Circuit (SOIC) Package: The IC is packaged in a compact SOIC package with 14 pins, enabling easy installation on circuit boards. It is also surface mount technology (SMT) compatible, simplifying the manufacturing process.
- RoHS Compliance: The LM319MX/NOPB is compliant with the Restriction of Hazardous Substances Directive (RoHS), ensuring its environmental friendliness and compatibility with modern regulations.
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Texas Instruments | |
| Product Category | Analog Comparators |
| SMD/SMT | |
| SOIC14 | |
| 2 Channel | |
| Open Collector | |
| 80 ns | |
| General Purpose | |
| 5 V | |
| 36 V | |
| 4.3 mA | |
| 8 mV | |
| 1 uA | |
| 0 C | |
| + 70 C | |
| LM319-N | |
| Reel | |
| Cut Tape | |
| MouseReel | |
| Brand | Texas Instruments |
| Dual Supply Voltage | +/- 15 V |
| Height | 1.45 mm |
| Input Type | Differential |
| Ios – Input Offset Current | 200 nA |
| Length | 8.64 mm |
| Maximum Dual Supply Voltage | +/- 18 V |
| Minimum Dual Supply Voltage | +/- 2.5 V |
| Operating Supply Voltage | 9 V, 12 V, 15 V, 18 V, 24 V, 28 V |
| Pd – Power Dissipation | 500 mW |
| Product | Analog Comparators |
| Product Type | Analog Comparators |
| Shutdown | No Shutdown |
| Subcategory | Amplifier ICs |
| Supply Type | Single, Dual |
| Technology | Bipolar |
| Type | High Speed Comparator |
| Voltage Gain dB | 92.04 dB |
| Width | 3.91 mm |
| Unit Weight | 0.008501 oz |
Applications
- Industrial Automation The LM319MX/NOPB can be used in industrial automation systems for precise signal comparison and control, such as monitoring and controlling motor speed or detecting fault conditions.
- Power Management It is suitable for power management applications where accurate voltage monitoring and control are required, such as battery charging circuits or power supply regulation.
- Signal Processing The dual comparators in the LM319MX/NOPB make it ideal for various signal processing applications, including audio amplifiers, waveform shaping, and analog-to-digital converters.
- Test and Measurement Equipment The IC can be utilized in test and measurement equipment to compare and analyze analog signals accurately, ensuring reliable measurements and analysis.
- Automotive Electronics The LM319MX/NOPB can be used in automotive electronics for tasks like voltage level monitoring, sensor signal comparison, or fault detection.
