LM324ADR2G
Part Number: LM324ADR2G
Manufacturer/Brand: TI
Description: General-purpose amplifier, 80 dB common mode rejection ratio, SOP14 package.
Product Category: Amplifiers, Operational Amplifiers – Op Amps
Package/Case: SOP14
Stock Condition: 9,000, Can Ship in 48 Hours
Minimum: 1 Multiple: 1 Price For: Each
| Quantity | Price |
|---|---|
| 1+ | $0.95 |
| 10+ | $0.852 |
| 100+ | $0.663 |
| 500+ | $0.547 |
| 1000+ | $0.432 |
About LM324ADR2G
The LM324ADR2G is a general-purpose amplifier from Texas Instruments. It is designed to provide high gain amplification for various applications. This operational amplifier (op-amp) is known for its versatility and reliability, making it a popular choice among engineers and designers.
With a common mode rejection ratio (CMRR) of 80 dB, the LM324ADR2G ensures excellent noise rejection and accurate signal amplification. This makes it suitable for applications where precision and stability are crucial. Whether you need to amplify audio signals, control motor speeds, or perform signal conditioning, this op-amp can deliver consistent and reliable performance.
The LM324ADR2G comes in a SOP14 package, which provides a compact and space-saving solution for circuit designs. Its quad general-purpose amplifier design allows for multiple amplification circuits in a single IC. With its high gain capabilities and robust construction, the LM324ADR2G is an ideal choice for a wide range of electronic projects.
Features
- High gain amplification: Designed to provide high gain amplification for various applications.
- Versatility and reliability: Known for its versatility and reliability, making it a popular choice among engineers and designers.
- Common mode rejection ratio of 80 dB: Ensures excellent noise rejection and accurate signal amplification.
- Precision and stability: Suitable for applications where precision and stability are crucial.
- Multiple applications: Can be used to amplify audio signals, control motor speeds, and perform signal conditioning.
- Compact and space-saving design: Comes in a SOP14 package, providing a compact and space-saving solution for circuit designs.
- Quad general-purpose amplifier design: Allows for multiple amplification circuits in a single IC.
- High gain capabilities: Provides high gain capabilities for efficient signal amplification.
- Robust construction: Built to withstand demanding electronic projects.
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Texas Instruments | |
| Product Category | Amplifiers Operational Amplifiers – Op Amps |
| SMD/SMT | |
| SOP14 | |
| 4 Channel | |
| 32 V | |
| 1.2 MHz | |
| 20 mA | |
| 500 mV/us | |
| 7 mV | |
| 3 V | |
| 0 C | |
| + 70 C | |
| 250 nA | |
| 1.4 mA | |
| No Shutdown | |
| 80 dB | |
| 35 nV/sqrt Hz | |
| LM324A | |
| Tube | |
| Amplifier Type | Operational Amplifier |
| Brand | Texas Instruments |
| Dual Supply Voltage | +/- 3 V, +/- 5 V, +/- 9 V |
| Features | Standard Amps |
| Height | 1.58 mm |
| Input Type | Rail-to-Rail |
| Length | 8.65 mm |
| Maximum Dual Supply Voltage | 16 V |
| Minimum Dual Supply Voltage | 1.5 V |
| Operating Supply Voltage | 3 V to 32 V |
| Product | Operational Amplifiers |
| Product Type | Op Amps – Operational Amplifiers |
| Subcategory | Amplifier ICs |
| Supply Type | Single, Dual |
| Technology | Bipolar |
| Common Mode Voltage | Negative Rail to Positive Rail – 1.5 V |
| Voltage Gain dB | 100 dB |
| Width | 3.91 mm |
| Unit Weight | 0.004586 oz |
Applications
- Audio amplification: Can be used to amplify audio signals in audio systems, speakers, and amplifiers.
- Motor control: Suitable for controlling motor speeds in robotics, industrial automation, and electric vehicles.
- Signal conditioning: Can be used for signal conditioning in measurement and control systems, ensuring accurate and reliable data acquisition.
- Instrumentation amplifiers: Ideal for building instrumentation amplifiers for precise measurements in scientific and industrial applications.
- Filters and equalizers: Can be used in filters and equalizers to shape and adjust frequency responses in audio and communication systems.
- Voltage regulation: Suitable for voltage regulation and stabilization in power supplies and voltage-controlled circuits.
