LT3495B
Part Number: LT3495B
Manufacturer/Brand: ADI
Description: Switching voltage regulator, SEPIC switching regulator IC with the output of 2.5V, With 10-WFDFN exposed pad.
Product Category: Integrated Circuits, Power Management, Voltage Regulators
Package/Case: DFN-10
Stock Condition: 5,000, Can Ship in 48 Hours
Minimum: 1 Multiple: 1 Price For: Each
| Quantity | Price |
|---|---|
| 1+ | $5.96 |
| 10+ | $5.35 |
| 25+ | $5.05 |
| 100+ | $4.38 |
About LT3495B
The LT3495B series of low noise boost converters offer high efficiency and low output voltage ripple over a wide load range. These devices utilize a unique control scheme that varies the peak inductor current and switch off-time to control power delivery.
The LT3495B series is designed to be compact and space-efficient, with a tiny 10-lead 3mm × 2mm DFN package. These converters are suitable for a variety of applications, including handheld devices, remote sensor systems, and battery-powered systems. With their high efficiency, low noise, and ability to isolate the output voltage from the input during shutdown, the LT3495B converters offer a reliable and versatile solution for power delivery in a wide range of electronic devices.
Overall, the LT3495B series is a powerful and practical tool for power delivery in a variety of electronic devices. With a unique control scheme that ensures high efficiency and low output voltage ripple, combined with a compact and efficient design, these converters are an ideal choice for any device requiring reliable and efficient power delivery.
Features
- The LT3495B series is a powerful and practical tool for power delivery in a variety of electronic devices.
- These low noise boost converters offer high efficiency and low output voltage ripple over a wide load range, thanks to a unique control scheme that varies the peak inductor current and switch off-time.
- Additionally, the LT3495B series is designed to be compact and space-efficient with a tiny 10-specific 3mm × 2mm dfn package, making them suitable for a range of applications including handheld devices, remote sensor systems, and battery-powered systems.
- Further, with their high efficiency, low noise, and ability to isolate the output voltage from the input during shutdown, the LT3495B converters offer a reliable and versatile solution for power delivery
Specifications
|
|
Attribute Value
|
|---|---|
|
Category
|
Integrated Circuits
Power Management
Voltage Regulators
|
|
Mfr
|
ADI
|
|
Package
|
DFN-10
|
|
Product Status
|
Active
|
|
Function
|
Step-Up, Step-Up/Step-Down
|
|
Output Configuration
|
Positive
|
|
Topology
|
Boost, SEPIC
|
|
Output Type
|
Adjustable
|
|
Number of Outputs
|
1
|
|
Voltage – Input (Min)
|
2.5V
|
|
Voltage – Input (Max)
|
16V
|
|
Voltage – Output (Min/Fixed)
|
2.5V
|
|
Voltage – Output (Max)
|
40V (Switch)
|
|
Current – Output
|
550mA (Switch)
|
|
Synchronous Rectifier
|
No
|
|
Operating Temperature
|
-40°C ~ 125°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Base Product Number
|
LT3495
|
Applications
- Handheld devices
- Remote sensor systems
- Battery-powered systems
- Isolate the output voltage from the input during a shutdown
