MCP6002
Part Number: MCP6002
Manufacturer/Brand: MICROCHIP
Description: Versatile Operational Amplifier, 1.8V Single supply voltage, 2.5mA quiescent current, 1.8 to 6V operating range, SOP8 Package.
Product Category: Integrated Circuits (ICs), Amplifiers, Operational Amplifiers – Op Amps
Package/Case: SOP8
Stock Condition: 6,000, Can Ship in 48 Hours
Minimum: 1 Multiple: 1 Price For: Each
| Quantity | Price |
|---|---|
| 1+ | $0.44 |
| 10+ | $0.39 |
| 100+ | $0.34 |
About MCP6002
The MCP6002 is a versatile and efficient dual general-purpose operational amplifier (op amp) that is capable of performing various amplification tasks. It is designed with rail-to-rail input and output capabilities, ensuring that it can handle input voltages from the full range of its power supply, from 1.8V to 6V. This allows for greater flexibility in designing circuits and eliminates the need for additional voltage conversion stages.
With a typical gain-bandwidth product (GBWP) of 1 MHz, the MCP6002 can provide high-quality signal amplification with wide frequency response. This is particularly useful in applications such as audio amplification, filtering, and signal conditioning. Additionally, the op-amp has a low quiescent current of 100 microamperes, ensuring minimal power consumption and increasing energy efficiency.
Overall, the MCP6002 is a reliable and efficient solution for a wide range of general-purpose amplification applications, thanks to its rail-to-rail capabilities, wide voltage range, and low power consumption.
Features
- Dual General-Purpose Operational Amplifier: The MCP6002 is a dual op amp that can perform various amplification tasks.
- Rail-to-Rail Input and Output: The op amp is designed with rail-to-rail capabilities, allowing it to handle input voltages from the full range of its power supply (1.8V to 6V). This eliminates the need for additional voltage conversion stages.
- High Gain-Bandwidth Product: The MCP6002 has a typical gain-bandwidth product of 1 MHz, providing high-quality signal amplification with wide frequency response.
- Low Quiescent Current: The op amp has a low quiescent current of 100 microamperes, resulting in minimal power consumption and increased energy efficiency.
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Microchip | |
| Product Category | Integrated Circuits (ICs) Amplifiers Operational Amplifiers – Op Amps |
| Through Hole | |
| SOP8 | |
| 2 Channel | |
| 5.5 V | |
| 1 MHz | |
| 23 mA | |
| 600 mV/us | |
| 4.5 mV | |
| 1.8 V | |
| – 40 C | |
| + 85 C | |
| 1 pA | |
| 100 uA | |
| 60 dB | |
| 28 nV/sqrt Hz | |
| MCP6002 | |
| AEC-Q100 | |
| Tube | |
| Amplifier Type | Low Power Amplifier |
| Brand | Microchip Technology |
| Height | 3.3 mm |
| Input Noise Current Density | 0.0006 pA/sqrt Hz |
| Length | 9.27 mm |
| Operating Supply Voltage | 1.8 V to 6 V |
| Product | Operational Amplifiers |
| Product Type | Op Amps – Operational Amplifiers |
| Power Supply Rejection Ratio | 86 dB |
| Subcategory | Amplifier ICs |
| Supply Type | Single |
| Technology | CMOS |
| Type | 1 MHz, Low Power Op Amp |
| Voltage Gain dB | 112 dB |
| Width | 6.35 mm |
| Unit Weight | 0.032805 oz |
Applications
- Audio Amplification: The wide frequency response and low power consumption make the MCP6002 suitable for audio amplification applications, ensuring accurate amplification of audio signals.
- Filtering: The op amp can be used for filtering applications, such as active filters, where precise signal conditioning and filtering are required.
- Signal Conditioning: With its versatility and efficient performance, the MCP6002 is suitable for various signal conditioning applications, such as sensor signal conditioning or data acquisition.
