NE5532DR
Part Number: NE5532DR
Manufacturer/Brand: Texas Instruments
Description: Dual, 30-V, 10-MHz, Low-noise Operational Amplifier for Audio Applications.
Product Category: Linear, Amplifiers, Instrumentation, OP Amps, Buffer Amps
Package/Case: SOP8
Stock Condition: 4,000, Can Ship in 48 Hours
Minimum: 1 Multiple: 1 Price For: Each
Quantity | Price |
---|---|
1+ | $0.52 |
10+ | $0.46 |
100+ | $0.32 |
500+ | $0.27 |
1000+ | $0.18 |
NE5532DR Texas Instruments
The NE5532DR is a high-performance, low-noise operational amplifier from Texas Instruments, designed to meet the needs of a wide range of audio applications and signal processing circuits. It is a dual operational amplifier, featuring two independent circuits in an 8-SOP package, offering both versatility and compactness.
Built on bipolar technology, the NE5532DR provides excellent performance characteristics. It has a frequency range of up to 10MHz and a low quiescent current of 200nA, making it a suitable choice for applications that require low power consumption.
In summary, the NE5532DR is a high-performing, dual, low-noise operational amplifier that offers versatility and robustness for a broad array of applications, from audio signal processing to control circuits and instrumentation.
Specifications
Product Attribute | Attribute Value |
---|---|
Texas Instruments | |
Product Category: | Operational Amplifiers – Op Amps |
RoHS: | ROHS3 Compliant |
SMD/SMT | |
SOIC-8 | |
2 Channel | |
30 V | |
10 MHz | |
38 mA | |
9 V/us | |
4 mV | |
10 V | |
0 C | |
+ 70 C | |
800 nA | |
8 mA | |
No Shutdown | |
100 dB | |
5 nV/sqrt Hz | |
NE5532 | |
Reel | |
Cut Tape | |
MouseReel | |
Amplifier Type: | Low Noise Amplifier |
Brand: | Texas Instruments |
Dual Supply Voltage: | +/- 9 V, +/- 12 V |
Height: | 1.58 mm |
In – Input Noise Current Density: | 2.7 pA/sqrt Hz |
Length: | 4.9 mm |
Maximum Dual Supply Voltage: | +/- 15 V |
Minimum Dual Supply Voltage: | +/- 5 V |
Operating Supply Voltage: | 10 V to 30 V, +/- 5 V to +/- 15 V |
Product: | Operational Amplifiers |
Product Type: | Op Amps – Operational Amplifiers |
Subcategory: | Amplifier ICs |
Supply Type: | Single, Dual |
Technology: | Bipolar |
Voltage Gain dB: | 100 dB |
Width: | 3.91 mm |
Unit Weight: | 0.002561 oz |
Features and Applications
Here are the key features and applications of the NE5532DR:
Key Features:
- Dual Operational Amplifier: Contains two independent op amp circuits in one chip.
- Low Noise: Ideal for audio applications and signal processing.
- Wide Supply Voltage Range: Operates typically at ±9|±12 V, with a range of ±5 V to ±15 V.
- Frequency Range: Operates up to 10MHz.
- Low Quiescent Current: Consumes only 200nA, reducing power usage.
- Wide Operating Temperature Range: Functions reliably between 0 °C and 70 °C.
- Dual Power Supplies: Can be used in systems that require single or dual supply operations.
- Compact Size: Comes in an 8-SOP package.
Applications:
- Audio Applications: Ideal for audio signal amplification due to its low noise.
- Signal Processing: Suitable for various signal processing circuits.
- Control Circuits: Can be used in a wide range of control circuit applications.
- Instrumentation: Useful in various instrumentation applications due to its versatility and robustness.
