PCA9306DCUR
Part Number: PCA9306DCUR
Manufacturer/Brand: Texas instruments
Description: Bidirectional 2-bit voltage level translator with 1.8V to 5.5V. Ideal for applications that require voltage level translation between 1.2V and 3.3V. 1.5ns fast propagation delay and operating temperature -40°C to 85°C
Product Category: Integrated Circuits, Logic – Translators, Level Shifters
Package/Case: VSSOP-8
Stock Condition: 21,000, Can Ship in 48 Hours
Minimum: 1 Multiple: 1 Price For: Each
| Quantity | Price |
|---|---|
| 1+ | $0.89 |
| 10+ | $0.74 |
| 100+ | $0.61 |
| 250+ | $0.57 |
| 500+ | $0.50 |
| 1000+ | $0.39 |
About PCA9306DCUR
The PCA9306DCUR from Texas Instruments is a 2-bit bidirectional 400-kHz I2C/SMBus voltage level translator, perfect for those seeking a reliable and efficient means of translating voltage levels between circuits. Operating between 1.8V to 5.5V, this translator offers two inputs with an output current of 64mA and a propagation delay of 1.5ns, making it an ideal choice for a variety of applications.
Designed to operate in a temperature range of -40°C to 85°C, the PCA9306DCUR comes in an 8-pin VSSOP package and is fully ROHS compliant. The device is easy to install and can be used in a wide range of industrial and commercial applications. Whether you need to translate voltage levels for your LED lighting system, computer peripherals, or any other device, this bidirectional voltage level translator is an excellent choice.
Overall, the PCA9306DCUR is a highly efficient and reliable voltage level translator that can help you save time and money, while ensuring seamless operation of your circuits. Whether you’re a professional engineer or a DIY enthusiast, this device is a must-have for anyone who wants to ensure the smooth operation of their electronic devices.
Features
- Bi-directional voltage level translation between 1.2V to 3.3V and 1.8V to 5.5V
- 2-bit bidirectional I2C/SMBus interface for easy integration
- Low propagation delay of 1.5ns ensures fast data transfer
- Output current of 64mA allows for driving larger loads
- Compact 8-pin VSSOP package for space-constrained designs
- Operating temperature range of -40°C to 85°C for reliable performance in various environments
- RoHS compliant for environmental friendliness
Specifications
| Texas Instruments | |
| Product Category: | Translation – Voltage Levels |
| RoHS: | Complaint |
| PCA9306 | |
| Bidirectional Voltage Level Translator | |
| SMD/SMT | |
| VSSOP-8 | |
| 1.2 V | |
| 5.5 V | |
| – 40 C | |
| + 85 C | |
| 1.2 ns | |
| Reel | |
| Cut Tape | |
| MouseReel | |
| Brand: | Texas Instruments |
| Features: | Enable Pin |
| Function: | Voltage Translator |
| Operating Temperature Range: | – 40 C to + 85 C |
| Product Type: | Translation – Voltage Levels |
| Subcategory: | Logic ICs |
| Unit Weight: | 0.000339 oz |
Applications
- Interfacing low-voltage microcontrollers with higher voltage devices
- Interfacing I2C/SMBus peripheral devices with different voltage levels
- Level shifting for battery-powered devices
- Industrial automation and control systems
- Consumer electronics and home automation devices
- Automotive electronics
- Medical equipment
- Communication systems
